General Specifications
| Part No. | BB25AV |
|---|---|
| Description | Process Sealed Subminiature Antistatic Pushbutton Switches |
| Name | PUSHBUTTON SWITCHES |
| Series | BB |
| Poles | DPDT |
| Circuits | On-(On) |
| Current Rating | 0.4VA (AC/DC) |
| Rating | 0.4 | Illumination | Non-Illuminated |
| Mounting Type | Through Hole |
| Keywords | Antistatic |
| Contact Finish | Gold Plating |
| Rating (AC) | 28V |
| Rating (DC) | 28V |
| Actuator Type | Round Cap(Optional Accessory) |
| Termination Style | Vertical PC Terminals |
