General Specifications
Part No. | FB15ANEP2 |
---|---|
Description | Momentary Pushbutton Switches |
Name | PUSHBUTTON SWITCHES |
Series | FB |
Poles | SPST |
Circuits | Off-(On) |
Current Rating | 500mA (AC) |
Rating | 0.5 | Illumination | Non-Illuminated |
Mounting Type | Panel Mount |
Rating (AC) | 125V |
Actuator Type | Round Cap(Optional Accessory) |
Panel Cutout Dimensions | 5.3Dia. |
Termination Style | Solder Lug |
Standards & Approvals | UL |
