General Specifications
Part No. | SB4011NOM |
---|---|
Description | 3 Amp Momentary Pushbutton Switches |
Name | PUSHBUTTON SWITCHES |
Series | SB |
Poles | SPST |
Circuits | Off-(On) |
Current Rating | 3A (AC) |
Rating | 3 | Illumination | Non-Illuminated |
Mounting Type | Panel Mount |
Rating (AC) | 125V |
Actuator Type | Round Button |
Actuator Cap Color | Black |
Panel Cutout Dimensions | 12.5Dia. |
Termination Style | Solder Lug |
Standards & Approvals | CSA,UL |
