General Specifications
| Part No. | M2112JCW01 |
|---|---|
| Description | Not recommended for new designs. Order due date : 2023/06/30 New Part Num.:MNL12JCW01 New PN Available to Order : 2024/01/15 |
| Name | ILLUMINATED ROCKER SWITCHES |
| Series | M |
| Poles | SPDT |
| Circuits | On-On |
| Current Rating | 6A (AC), 3A (DC) |
| Rating | 6 | Illumination | Illuminated |
| Mounting Type | Panel Mount, Snap-In |
| Contact Finish | Silver |
| Rating (AC) | 125V |
| Rating (DC) | 30V |
| Actuator Type | Paddle Cap |
| Actuator Cap Color | Black |
| Panel Cutout Shape | No Marking |
| Termination Style | Solder Lug |
| Illumination Type | LED |
| Illumination Color | Red |
