General Specifications
| Part No. | S302T |
|---|---|
| Description | Low-High Capacity Standard Toggle Switches |
| Name | TOGGLE SWITCHES |
| Series | S |
| Poles | SPDT |
| Circuits | On-On |
| Current Rating | 15A (AC/DC) |
| Rating | 15 | Illumination | Non-Illuminated |
| Mounting Type | Panel Mount |
| Rating (AC) | 125V |
| Rating (DC) | 30V |
| Actuator Type | Standard Round |
| Panel Cutout Dimensions | 12.5Dia. |
| Termination Style | Screw Terminal |
| Standards & Approvals | CSA,UL |
